S661 Connecting link - 316

SKU: 66610316

Size: 3/16"
Price:

Login to view the price.

Stock:
Login to view stock.

Description

Technical Data:
Casting Material:
AISI304 - DIN 1.4308/
AISI316 - DIN 1.4408
Production:
S661 - Link - Cast
Surface Treatment:
“E.P.” (Electro polished)

Note : Standard safety factor for working load
is 1/4 of breaking load.

DATA SHEET DOWNLOAD

Model

S661

Connecting link
316 ss

S661 drawing
S661 image
SS316SIZEB (mm)C (mm)T (mm)Unit weight (kgs)B.L. (kgs)
666103163/16"8.517.0050.01550
666101041/4"10.520.8060.02800
666105165/16"1224.0080.031,450
666103083/8"1528.259.50.061,900
666107167/16"16.532.50110.092,550
666101021/2"18.536.7512.50.123,200
SS316SIZEB (inch)C (inch)T (inch)Unit weight (lb)B.L. (lb)
666103163/16"0.330.670.200.021,210
666101041/4"0.410.820.240.041,760
666105165/16"0.470.940.310.071,900
666103083/8"0.591.110.370.134,180
666107167/16"0.651.280.430.205,610
666101021/2"0.731.450.490.267,040
